Octagonal columns

Octagonal columns provide extreme versatile combination of mounting heights, base types and outreach options making it the most widely used range of columns. We manufacture octagonal (8 sided) tapering sheet steel lighting columns for mounting heights from 3 to 30m, these are available in root mounted, flange mounted or mid hinged versions. The octagonal column is suitable for post top mounting or a variety of outreach or extension brackets and t bars are available to suit. Choose a bracket with 89mm socket or fitting with a 76mm diameter post top.

Details

3mt

Octagonal Column

Request Full Specification link

OC3X76 OFC3X76

4mt

Octagonal Column

Request Full Specification link

OC4X76 OFC4X76

5mt

Octagonal Column

Request Full Specification link

OC5X76 OFC5X76

6mt

Octagonal Column

Request Full Specification link

OC6X76 OC6X76-60S OFC6X76

8mt

Octagonal Column

Request Full Specification link

OC8X76 OC8X76-60S OC8X76-1PCE OC8X76-1.2PD OFC8X76

10mt

Octagonal Column

Request Full Specification link

OC10X76 OC10X76-1.5PD

12mt

Octagonal Column

Request Full Specification link

OC12X130 OC12X76-X1.7PD

14mt

Octagonal Column

Request Full Specification link

Base Compartments

Base Compartments

Standard columns are supplied with a single access opening and fitted within the door compartment. The compartment has a welded in frame with recessed weather strip, with a flat steel door fitted and secured by two triangular headed stainless steel bolts.

Base compartment is large enough to offer easy access to the equipment, which can be mounted on the hardwood baseboard within.

Design

All these Lighting Columns are manufactured and designed in accordance with the requirements of the Department of the Environment and local authorities and where appropriate comply with the NRA Specification. These Lighting Columns will all fully comply with the new European Standard EN40.

Columns are galvanised internally and externally to BS EN 1461. And can be painted to customer specifications.

Bitumen paint is applied internally and externally on the root section of the columns for protection.
